30x165 mm ROUNDS FOR AUTOMATIC GUNS 2A38, 2A42 AND 2A72

TP,HE-T INERT

TP,HE-T INERT

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

30x165 mm Rounds Inert
and TP with Target Practice

NSN:1305-50-001-2995

30x165 mm Rounds HE-T Inert

NSN:1305-50-001-2994



The Rounds are compatible with automatic guns 2A38, 2A42, 2A72, mounted on Infantry Fighting Vehicles BMP-2, BMP-3, BMD-2, BMD-3, BTR-80A; Reconnaissance Vehicle "RIS"; Air-Defence Complex "€žTunguska"€œ; Attack Helicopters Ka-50, Mi-28 and Mi-24P.


The Round are intended for training purposes.

Packing
18 Rounds in one airtight metal box, three metal boxes (54 pcs. totally) in a wooden case
Wooden case dimensions, mm875x398x206
Gross weight, kg65
Volume, m30.072
Specifications
TPHE-T INERT
Calibre, mm30x16530x165
Projectile typeTarget Practice-
Round length, mmfrom 289.45 to 292.84from 288.45 to 291.84
Round weight , g842 approx.835 approx.
Projectile weight, g389 approx.385 approx.
PrimerKV-3-1KV-3-1
Tracer burning time, s-Not less than 9
Fuze typeBallistic cupBallistic cup
Average muzzle velocity, Voaver, m/s960960
Average max Pressure at 15 °C Pmaxaver, Mpanot more than 353.04not more than 353.04
Propellant type6/7 P-5 BPfl6/7 P-5 BPfl
Case materialSteel (zinc plated)Steel (zinc plated)
Operational temperature range, °Cfrom minus 50 to 50from minus 50 to 50
CLASS OF EXPLOSION HAZARD1.2C; UN 0328
