82 mm Mortar Bombs

82 mm HE 82M

82 mm HE 82M

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

82 mm Mortar Bombs HE 82 M

HE 82M: NSN 1315-50-001-5483



The 82 mm HE 82M Mortar bomb is intended for firing of 82 mm Mortars for destroying the manpower and fire weapons in the open, in trenches and entrenchments.

The optimum blast and fragmentation effect of approximately  1 250 effective fragments is achieved by the use of spheroidal graphite cast iron with predominately ferritic structure.

Main Features:

82 mm HE 82M can be fired from the following weapons: 82 mm Mortar M82MA, 82 mm Mortars of Russian standard: mod. 1937, mod. 1941, mod. 1943, 52-M-832, etc.

This Mortar Bomb is fuzed with AF611 (Point detonating, super quick action, boresafe type) fuze and Ignition Cartridge and up to 3 Increment Charges.

BALLISTIC DATA
HE 82M
Maximum Pressure (Crusher), kgf/cm2430 (0+3)
Max. range, m3 107 (0+3)
Muzzle velocity, m/s211 (0+3)
BASIC CHARACTERISTICS
HE 82M
Body materialSpheroidal Graphite Cast Iron
Length fuzed, mm345 max
Weight fuzed, kg3.180 max
Weight of Explosive charge (TNT), kg0.420 max
Highest Max Pressure (Crusher), kgf/cm2490 (0+3)
Operating Temperature Range, °Cfrom minus 40 to 50
Packing
HE 82M
TypeOne fuzed Mortar Bomb with 3 pcs. Increment charges is packed in a Container; 12 pcs. Containers are arranged in a wooden case.
Wooden case dimensions, mm653x440x268
Case weight, kg56
Case volume, m30.077
Class of explosion hazard, UN Code1.2E, UN 0321
