CEMENTED CARBIDE TIPS

CARBIDE GRADES FOR TURNING

CARBIDE GRADES FOR TURNING

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

CARBIDE GRADES FOR TURNING

Main Features:

  • Turning and Milling inserts for all fields of application according to ISO, including four grades with single and double layer wear-resistant coatings.
  • All types brazed tips according to BNS 13673-13689 (Bulgarian National Standard) and ON 04 72225-04 72244 (Working standard) made of our 16 cemented carbide grades.
  • Solid carbide end mills
  • Drawing cemented carbide nozzles, dies, wear parts and cemented carbide blanks.
BASIC CHARACTERISTICS
FIELD OF APPLICATION ACC. TO ISO BasicFIELD OF APPLICATION ACC. TO ISO SupplementaryMACHINING TYPE
BS1PP10P01-P15Finishing of steel and steel castings. Favourable conditions. High cutting speeds, moderate feeds. Suitable for surface turning.
BS4, BS30P30P25-P35Medium heavy roughing of steel and steel casting under unfavourable conditions. Comparatively low cutting speeds, heavy feeds.
BS6P40M30P30-P45M15-M40Heavy roughing of steel and steel castings. Difficult conditions. Low cutting speeds, heavy feeds, large cutting depths.
BH20,BH30M20K20M15-M30K15-K25Heavy roughing of cast iron under unfavourable conditions. Low cutting speeds, heavy feeds. Light and rough machining of heat resistant alloys . Also for difficult machining conditions, high wear resistance.
BH1P,BH15K10K01-K20Finishing and light roughing of cast iron. Also for alloyed cast iron, bronze and brass. Relatively high cutting speeds and moderate feeds.
BR1PM10Finishing and light roughing of heat resistant alloys and stainless steel. High resistance to notch wear. Comparatively high cutting speeds, moderate feeds. Especially suitable for surface turning.
BSHM20Grade for special applicatoins. Heavy roughing of MN-steels and ductile alloy cast iron with a longchipping tendency. Suitable re-turning of raiway wheels.
