AF71,AF72

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Fuzes for Fragmentation and High-Explosive Fragmentation rounds
for ARSENAL ATGL-H, ATGL-L family. Russian SPG-9 ,RPG-7V and 2A28 Gun

AF71 NSN:1390-50-001-1750

AF72

BASIC CHARACTERISTICS	AF71	AF72
Mass of fuze, g	204	200
Overall dimensions, mm	Ø40x133	Ø40x133.5
Type of explosive filling	TEN	TEN
Mass of explosive filling, kg	0.01	0.01
Height of safe falling, m	up to 3	up to 2.5
Operation temperature range, °C	from minus 50 to 50	from minus 50 to 50
