AF11, AF12, AF13,AF16

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Fuzes for Hand Grenades

AF11
NSN:1330-50-000-7199

AF12

NSN:1330-50-001-0764

AF13

NSN:1330-50-001-0765

AF16

NSN:1330-50-001-2512

BASIC CHARACTERISTICS	AF11	AF12	AF13	AF16
Type of the Grenade	GHO-1, GHO-2, GHD-1, GHD-2, GHTB	GHO-1P, GHD-2P	GHD-1, GHD-2, GHTB	GHD-4
Mass of fuze, g	38	38	42	38
Thread size	Sp M15.45x13 turns in 1"	Sp M15.45x13 turns in 1"	Sp M15.45x13 turns in 1"	Sp M15.45x13 turns in 1"
Overall dimensions, mm
● Height	85.3	85.3	85.3	85.3
● Width	47	47	47	47
Time of delay, s	from 3.2 to 4.2	from 3 to 5	from 3.2 to 5	from 3,2 to 5
Operational temperature range,°C	from minus 43 to 52	from minus 30 to 52	from minus 43 to 52	from minus 43 to 52
Dimensions of the packing (metal box), mm	Ø102, H115	Ø102, H115	Ø102, H115	Ø102, H115
Number of fuzes in one packing, pcs.	10	10	10	10
Gross weight of packing with fuzes, kg	0.56	0.56	0.6	0.56
