AF61, AF611, AF621, AF64

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Fuzes for Mortar Bombs AF61

NSN: 1390-50-001-0768

Fuzes for Mortar Bombs AF611

NSN:1390-50-001-1768

Fuzes for Mortar Bombs AF621

NSN:1390-50-000-0730

NSN:1390-50-001-0766

BASIC CHARACTERISTICS	AF61	AF611	AF621	AF64
Ammunition type	HE82	HE82	HE60MA, HE60LDMA, HE81LDMA, HE82LD	HE60MA, HE60LDMA, HE81LDMA, HE82LD
Mass of fuze, g, approx.	160	170	207	198
Thread size	Sp 36.18x10 turns in one inch	36.18x10 turns in one inch	1.5"-12 UNF-1A	1.5"-12 UNF-1A
Overall dimensions, mm	ø40x83.4	Ø40x83.4	Ø48.5x88.5	Ø48.5x87.5
Operational temperature range,°C	from minus 50 to 50	from minus 50 to 50	from minus 50 to 50	from minus 40 to 60
