AF41

AF41

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

Fuze for Rounds for 40 mm Underbarrel Grenade Launchers of ARSENAL UBGL family,
GP-25 and GP-30. 40x46 mm Underbarrel Grenade Launchers of
ARSENAL UBGL-M family. M203 type and Grenade Launchers of M79 type

BASIC CHARACTERISTICS
AF41 (VMG-K)
Ammunition type40 mm RLV-HEF, RLV-FM, VOG-25 and 40x46 mm RLV-F
Mass of fuze, g47
Quantity of safety barriers3
Time of self-destruction, sfrom 14 to 19
Operational temperature range, °Cfrom minus 50 to 50
Arming distance, mfrom 10 to 40
