Primers for artillery Cartridges

GUV-7

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

The Primer Sleeve GUV-7 is intended to ignite the Propellant Charges with high pressure of artillery and tank ammunition(cal.115 mm, 122 mm and 125 mm) for electrically triggered systems.
It is ativated upon impact or under voltage

PACKING
Primer sleeves in a cardboard box	24 pcs.
Cardboard boxes (totally 192 Primer sleeves) in an airtight metal box	8 pcs.
Metal sealed boxes (totally 576 pcs. Primer sleeves) in a wooden case	3 pcs.
Wooden case dimensions, mm	875x398x206
Wooden case gross weight, kg	67
Wooden case volume, m³	0.072
CLASS OF EXPLOSION HAZARD	1.4 S, UN 0454

TECHNICAL CHARACTERISTICS	GUV-7
Diameter, mm	30
Overall height, mm	24
Fixing thread, mm	Sp. 27.178 x 14 turns per inch, class 2
Weight, g	88
Maximum pressure, kgf/cm²	5000
Activation voltage, V	20
Operational temperature range, °C	from minus 40 to 50
