M-21HE-ARS

M-21HE-ARS

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

TECHNICAL CHARACTERISTICS
M-21HE-ARS
Caliber, mm122
Rocket weight, kg
● Without fuze66.2 max
Rocket length, mm
● Without fuze2754 max
Maximum firing range, m20127
Operation temperature range, °Cfrom minus 40 to 50
COMPLETION
FuzeAF81
Ballistic brake ringsbig and small
PACKING
1 (one) unfuzed 122 mm Unguided Rocket M-21HE-ARS is packed in a wooden case
Unfuzed 122 mm Unguided Rocket M-21HE-ARS
Wooden case dimensions, mm2810x290x260
Wooden case GROSS weight, kg100
Wooden case volume, m30.212
CLASS OF EXPLOSION HAZARD1.2E, UN 0182
Fuze AF81
3 metal boxes are packed in one wooden case (totally 36 Fuzes per wooden case)12 Fuzes are packed in a metal airtight box
Wooden case dimensions, mm875 x 398 x 206
Wooden case GROSS weight, kg18
Wooden case volume, m30.022
CLASS OF EXPLOSION HAZARD1.2B, UN 0107
Ballistic Brake Rings
40 (forty) Ballistic Brake Rings-big and 40 (forty) Ballistic Brake Rings-smallpacked in a wooden case
Wooden case dimensions, mm380x290x202
Wooden case GROSS weight, kg18
Wooden case volume, m30.022
