40 mm OGi-7MA

40 mm OGi-7MA

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing



40 mm Round improved Fragmentation Anti-Personnel Round OGi-7MA

NSN:1310-50-001-4071

Improved, modernized version of Fragmentation
Anti-Personnel Rounds for RPG-7V



Main Features:

The Round  OGi-7MA are designed for destroying enemy manpower and weapon positions in the open, in trenches,
in field shelters, in light-armoured vehicles, and in non-armoured materiel by direct fire on the embrasures of field fortifications
and within urban areas.

Performance:

  • the increased effectiveness Grenades body with pre-fragmented elements;
  • increased fragmentation ( over 1250 fragments, OGi-7MA);
  • point-detonating fuzes AF76 and AF72 with super-quick and graze (anti-ricochet)function, independent of impact angle.
Packing
18 Rounds are packed in a wooden case as follows
18 Grenades, each one in airtight plastic bag;Each Round is packed in a plastic container, sealed with self-adhesive tape.
18 Propellant Charges CP-71, (each one in a plastic container; each 3 pcs. plastic containers in an airtight plastic bag).18 pcs of Rounds (3 layers of 6 rounds each) are accommodated in a wooden case.
TECHNICAL CHARACTERISTICS
OGi-7MA
Caliber, mm40
Maximum range, mover 1000
Direct fire range, m180
Weight of the round, kg1.75 max
Weight of the grenade, kg1.37 max
Muzzle velocity, m/s152
Lethal radius, mover 22
Fire rate, shots/minfrom 4 to 6
Operation temperature range, °Cfrom minus 40 to 50
The Round consists
FuzePoint-detonating fuze AF72 with super-quick and graze(anti-ricochet) function, independent of impact angle
Fragmentation GrenadeOGi-7
Propellant ChargeCP-711
Weapon Systems
All 40 mm ARSENAL ATGL-L Family and Russian RPG-7V Light Anti-Tank Grenade Launchers.
Wooden case
Dimensions, mm810x365x232
Weight, kg47
Volume, m30.069
CLASS OF EXPLOSION HAZARD1.1F, UN 0292
