Rounds for Light Anti-tank Recoilless Systems (ATGL-L Family and Russian RPG-7V)

40/106 mm RSMK-7MA

40/106 mm RSMK-7MA

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

40/106 mm Round RSMK-7MA with Smoke Grenade GSMK-7MA

NSN:1310-50-001-3758

Main Features:

The 40/106 Round RSMK-7MA with Smoke Grenade GSMK-7MA is intended for

  • marking targets;
  • creation of smoke curtains for the needs of army action camouflage;
  • creation of insufferable conditions in closed areas, igniting points of fire and emitting smoke that blinds enemy`s points of reconnaissance, surveillance and aimed fire.



Except smoke creation, the round due to the smoke composition, on the base of red phosphorous, provides incendiary effect.

The Round consists of Grenade GSMK-7MA and Propellant Charge CP-73. The Grenade consists of Front Smoke part SMK-7MA, Sustainer motor SM-71, and Point Detonating Fuze AF72.

Packing
6 Rounds are packed in a wooden case as follows
6 Grenades GILL-7MA (each one in airtight plastic bag)
6 Propellant Charges CP-713 (each one in a plastic container; each 3 pcs. plastic containers in an airtight plastic bag).
TECHNICAL CHARACTERISTICS
RSMK-7MA
Caliber, mm40
Warhead calibre, mm106
Weight of Round, kg4.6 max
Weight of the grenade, kg4.2
Max  sighting range, m (SGL-7MA with adjustable drum scale)1 200
Max direct fire range, m (Optical scale of SGL-7MA)200
 Muzzle velocity, m/s70
Fire rate, shots/min            4÷6
Smoke colourwhite
Smoke composition typeSMK-1(based on Red phosphorous)
Weight of smoke composition, kg2.190
Time of smoke creation, s5 max
Smoke Duration, s90
Volume of smoke cloud, m3             128x103 min
Operation temperature range, °Cfrom minus 40 to 50
The Round consists
FuzeAF72 with super-quick and graze (anti-ricochet) function, independent of impact angle
Smoke GrenadeGSMK-7MA
Sustaine MotorSM-71
Propellant ChargeCP-73
CLASS OF EXPLOSION HAZARD1.2G, UN 0015
Weapon Systems
ARSENAL ATGL-L2 and Russian RPG-7V Light Anti-Tank Grenade Launchers
Wooden case
Dimensions, mm895x481x325
Weight, kg50
Volume, m30.14
