Rounds for Light Anti-tank Recoilless Systems (ATGL-L Family and Russian RPG-7V)

40/73 mm RHEAT-7MA2

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Packing

40/73 mm Round RHEAT-7MA2 with Anti-Tank Grenade GHEAT-7MA2

NSN:1310-50-001-3757

Improved, modernized version of Anti-Tank Rounds for RPG-7V

Overview

The 40/73 mm RHEAT-7MA2 is designed for destroying tanks, self- propelled guns, and other armoured vehicles. It can also be used against enemy troops and weapon emplacements in trenches, field shelters or in brick-wall fortifications.

Performance :

Higher accuracy and low dispersion;
Max sighting range - 500 m.

Packing 6 Rounds are packed in a wooden case as follows
6 Grenades (each one in airtight plastic bag)
6 Propellant Charges (each one in a plastic container; each 3 pcs. plastic containers in an airtight plastic bag).

TECHNICAL CHARACTERISTICS	RHEAT-7MA2
Caliber, mm	40
Warhead calibre, mm	73
Armour penetration, mm	300
Max sighting range, m	500
Range of direct firing against a target with 2 m height, m	300
Weight of the round, kg	2.0 max
Weight of the grenade, kg	1.6
Average Muzzle velocity, m/s	140
Fire rate, shots/min	4-6
Operational temperature range, °C	from minus 40 to 50
The Round consists
Fuze	Piezoelectric AF78
Anti-tank Grenade	GHEAT-7MA2
Sustainer Motor	SM-73
Propellant Charge	CP-71

Weapon Systems
All 40 mm ARSENAL ATGL-L Family and Russian RPG-7V Light Anti-Tank Grenade Launchers.

Wooden case
Dimensions, mm	844x429x251
Weight, kg	30
Volume, m³	0.091
