Rounds for Light Anti-tank Recoilless Systems (ATGL-L Family and Russian RPG-7V)

40/73 mm RHEF-7MA

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Packing

40/73 mm Round RHEF-7MA with High-explosive Fragmentation Anti-Personnel Grenade GHEF-7MA

NSN:1310-50-001-1671

Improved, modernized version of High-Explosive Fragmentation Anti-Personnel Rounds for RPG-7V

Main Features:

The 40/73 mm Round RHEF-7MA with High-Explosive Fragmentation Grenade GHEF-7MA is designed for destroying enemy troops and fire means in the open, in trenches, in hasty field shelters or brick-wall fortifications, as well as against hostile unarmoured motorized vehicles and the infantry.

The Round consists of High-explosive Grenade GHEF-7MA and Propellant Charge CP-73.

The Grenade is completed with warhead consisting of pre-fragmented steel body and bursting charge of powerful explosive mixture of high-explosive or high-explosive incendiary action (at the customer's request); Sustainer Motor SM-71 and point-detonating Fuze AF72 with super-quick and graze (anti-ricochet) function, independent of impact angle.

Packing 6 Rounds are packed in a wooden case as follows
6 Grenades GHEF-7MA (each one in airtight plastic bag)
6 Propellant Charges CP-73 (each one in a plastic container; each 3 pcs. plastic containers in an airtight plastic bag).

TECHNICAL CHARACTERISTICS	RHEF-7MA
Caliber, mm	40
Warhead calibre, mm	73
Maximum fire range, m	1 200
Direct fire range, m	150
Weight of the round, kg	4.700 max
Weight of the grenade, kg	4.300 max
Muzzle velocity, m/s	70
Type of the explosive charge	A-IX-1 (RDX)
Weight of the explosive charge, kg	0.800 max
Fragmentation-prefabricated lethal fragments in weight 1.0...2.0 g, pcs	over 1 100
Fire rate, shots/min	4÷6
Operational temperature range, °C	from minus 40 to 50
The Round consists
Fuze type	Point-detonating Fuze AF72 with super-quick and graze (anti-ricochet) function, independent of impact angle
CLASS OF EXPLOSION HAZARD	1.1F, UN 0292

Weapon Systems
40 mm ARSENAL ATGL-L2 and Russian RPG-7V Light Anti-Tank Grenade Launchers.

Wooden case
Dimensions, mm	895x481x275
Weight, kg	51
Volume, m³	0.118
