23x152 mm ROUNDS FOR AIR DEFENCE SYSTEMS ADS, ADS-N, ZU-23-2, ZU-23-2F AND ZSU-23-4

RAPIT-C,API,API-T,AP-T

RAPIT-C,API,API-T,AP-T

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

23x152 mm Round RAPIT-C Armour-Piercing Incendiary Tracer Projectile with
tungsten alloy core

NSN:1305-50-001-4074

23x152 mm Round API with Armour Piercing Incendiary Projectile

NSN:1305-50-001-1898

 23x152 mm Round API-T with Armour Piercing Incendiary Tracer Projectile

NSN:1305-50-000-0303

23x152 mm Round AP-T with Armour Piercing Tracer Projectile

NSN:1305-50-000-0419

Overview

The Rounds are compatible with 23 mm ADS, ADS-N,  ZU-23-2, ZU-23-2F and ZSU-23-4
and intended to defeat air targets, ground unarmored and light armored vehicles .

Packing
28 Rounds in one airtight metal box, three metal boxes ( 84 pcs. totally ) in a wooden case
RAPIT-CAPI-TAP-T
Wooden case dimensions, mm875x398x206875x398x206875x398x206875x398x206
Gross weight, kg55555555
Volume, m30.072
Specifications
RAPIT-CAPIAPI-TAP-T
Caliber, mm23x152 mm23x152 mm23x152 mm23x152 mm
Projectile typeArmour Piercing Incendiary with TracerArmour Piercing IncendiaryArmour Piercing Incendiary with TracerArmour Piercing  Tracer
Round length, mmfrom 234.36 to 237.16from 234.36 to 237.16from 234.36 to 237.16from 234.36 to 237.16
Round weight, g450 approx.450 approx.450 approx.450 approx.
Projectile weight, g193 approx.185.6 approx.185.6 approx.185.6 approx.
PrimerPercussion Primer No3Percussion Primer No3Percussion Primer No3Percussion Primer No3
Tracer burning time, snot less than 3-not less than 5not less than 5
Average muzzle velocity, V0aver , m/s970970970970
Average max Pressure at 15°C PmaxaverMpanot more than 286.84not more than 286.84not more than 286.84not more than 286.84
Penetration*, distance, mmat 700 m: 30 mm at 1 000 m: 25 mmat 700 m: 15 mm at 1 000 m: 10 mmat 700 m: 15 mm at 1 000 m: 10 mmat 700 m: 15 mm at 1 000 m: 10 mm
Propellant type5/7 Cfl5/7 Cfl5/7 Cfl5/7 Cfl
Case materialsteelsteelsteelsteel
Operational temperature range, °Cfrom minus 50 to 50from minus 50 to 50from minus 50 to 50from minus 50 to 50
CLASS OF EXPLOSION HAZARD1.2C, UN 03281.2C, UN 03281.2C, UN 03281.2C, UN 0328
*Penetration test is proved by firing on 15 mm armour plate, placed at 100 m from the muzzle, at 600 towards the firing line and projectile impact velocity Vimpact=680± 20 m/s.
