40 mm Rounds Low Velocity for grenade launchers ARSENAL UBGL family, GP-25 and GP-30,GP-34 types.

40 mm RLV-CS-1 Grenade with CS composition

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Packing

40 mm RLV-CS-1 Grenade with CS composition

RLV-CS-1

NSN: 1310-50-001-2602

The 40 mm Rounds RLV-CS-1 type produce a gas cloud with concentration of irritants CS which causes severe irritation to the eyes, upper respiratory tract and skin.
The purpose of the intended use: to obtain the incapacitating effect, i.e. temporarily incapacitate a person, preventing from active well-directed operations and physical aggressive activity.

Overview

The Rounds are compatible with:

ARSENAL UBGL, UBGL-1, GP-25, GP-30 and GP-34 Underbarrel Grenade launchers mounted on ARSENAL Assault Rifles AR-M1, AR-M1F, AR-M7F, AR-M9, AR-M9F, etc.;
and on AK-74, AKS-74, AKM, AKMS, AK 101, AK 103;
40 mm MSGL-M Grenade Launcher - revolver type;
40 mm ARSENAL Stand-alone Grenade Launcher SAGL.

Packing 3 metal airtight boxes (40 pcs. in each box), placed in a wooden case (120 pcs. totally)	RLV-CS-M
Case dimensions, mm	875x398x206
Case weight, kg	47
Case volume, m³	0.072

Specifications	RLV-CS-1
Type	Low Velocity, CS
Calibre, mm	40
Overall length, mm	108 max
Weight of round, kg	0.257 max
Irritant agent	CS
Propellant	P-200
Primer type	KVM-3
Grenade body	Alluminum allow
Time of active gas emission, s (Discharge time)	12 min discharging time
Max firing range, m	400
Muzzle velocity, m/s	76
Radius of action, m	approx. 100
Fuze type	AF415 -Igniting Fuze, point detonating, distant arming and self destruction
Arming distance, m	from 9 to 28
Self-destruction time, s	from 14 to 19
Operation temperature , °C	from minus 50 to 50
CLASS OF EXPLOSION HAZARD:	1.4G (6.1, 8); UN 0301
Payload:	50g of pyrotechnic composition containg 7.5 g of CS (15%)
