40 mm Rounds Low Velocity for grenade launchers ARSENAL UBGL family, GP-25 and GP-30,GP-34 types.

40 mm RLV-FJM

40 mm RLV-FJM

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

40 mm Round RLV-FJM with Fragmentation Jump Grenade

NSN: 1310-50-001-2470

The Rounds are improved versions of this type of ammunition, provides effective against enemy troops in open terrain or in light shelters at distances from 40 m to 400 m.

Overview


The Rounds are compatible with:

Packing
3 metal airtight boxes (34 pcs. in each box), placed in a wooden case (102 pcs. totally)
Case dimensions, mm875x398x206
Case weight, kg48
Case volume, m30.072
Specifications
RLV-FJM
TypeLow Velocity, High-explosive Fragmentation Jump
Calibre, mm40
Overall length, mm107 max
Weight of Round, kg0.287 max
Weight of the explosive charge, kg0.055
Max firing range, m400
Muzzle velocity, m/s76
Jump height, mfrom 0.5 to 2.5
Radius of defeat, mnot less than 9
Explosive fillingA-IX-1 (RDX)
PropellantP-200
Primer typeKVM-3
Fuze typeAF43 - Point Detonating, distant Armed, self-destruction with ejection charge
Arming Distance, mfrom 10 to 40
Self-destruction time, sfrom 14 to 19
Operational temperature, °Cfrom minus 50 to 50
CLASS OF EXPLOSION HAZARD:1.1E; UN 0006
