40 mm Rounds Low Velocity for grenade launchers ARSENAL UBGL family, GP-25 and GP-30,GP-34 types.

40 mm RLV-FM

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

Features

Specifications

Accessories

Packing

40 mm Round RLV-FM with Fragmentation Grenade

NSN: 1310-50-001-2469

The Rounds 40 mm RLV-FM are improved versions of this type of ammunition, provides effective against enemy troops in open terrain or in light shelters at distances from 40 m to 400 m.

Overview

The Rounds are compatible with:

ARSENAL UBGL, UBGL-1, GP-25, GP-30 and GP-34 Underbarrel Grenade launchers mounted on ARSENAL Assault Rifles AR-M1, AR-M1F, AR-M7F, AR-M9, AR-M9F, etc.;
and on AK-74, AKS-74, AKM, AKMS, AK 101, AK 103;
40 mm MSGL-M Grenade Launcher - revolver type;
40 mm ARSENAL Stand-alone Grenade Launcher SAGL.

Specifications	RLV-FM
Type	Low Velocity, High-explosive Fragmentation
Calibre, mm	40
Overall length, mm	107 max
Weight of Round, kg	0.273 max
Weight of the explosive charge, kg	0.065
Max firing range, m	400
Muzzle velocity, m/s	76
Jump height, m	N/A
Radius of defeat, m	not less than 9
Explosive filling	A-IX-1 (RDX)
Propellant	P-200
Primer type	KVM-3
Fuze type	AF41-Point Detonating, super quick and check action, distant arming and self-destruction
Arming Distance, m	from 10 to 40
Self-destruction time, s	14 to 19
Operational temperature, °C	from minus 50 to 50
CLASS OF EXPLOSION HAZARD:	1.1E; UN 0006
