40 mm RLV-HEF

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Overview

40 mm Round RLV-HEF with HE Fragmentation Grenade

NSN: 1310-50-000-0285

The RLV-HEF provides effective action against enemy troops in open terrain or in light shelters at distances from 40 m to 400 m.

The Rounds are compatible with:

ARSENAL UBGL, UBGL-1, GP-25, GP-30 and GP-34 Underbarrel Grenade launchers mounted on ARSENAL Assault Rifles AR-M1, AR-M1F, AR-M7F, AR-M9, AR-M9F, etc.; and on AK-74, AKS-74, AKM, AKMS, AK 101, AK 103;
AVALANCHE Grenade Launcher - revolver type.

Packing 3 metal airtight boxes (40 pcs. in each box), placed in a wooden case (120 pcs. totally)
Wooden case dimensions, mm	875x398x206
Case weight, kg	47
Case volume, m³	0.072

Specifications	RLV-HEF
Type	Low Velocity, High Explosive Fragmentation
Calibre, mm	40
Overall length, mm	102.6 max
Weight of round, kg	0.250 max
Weight of explosive charge, kg	0.048 max
Max firing range, m	400
Muzzle velocity, m/s	76
Radius of defeat, m	not less than 6
Explosive filling	A-IX-1
Propellant	P-200
Primer type	KVM-3
Fuze type	AF41 - point detonation, time and super quick with check action and self-destruction
Arming distance, m	from 10 to 40
Self-destruction time, s	from 14 to 19
Operation temperature degrees, °C	from minus 50 to 50
CLASS OF EXPLOSION HAZARD	1.1E; UN 0006
