40x46 mm Rounds Low Velocity for grenade launchers ARSENAL UBGL-M family, M 203 , HK 69, etc. NATO Launchers

40x46 mm RLV-S&F

Caliber

5.56/7.62

Barrel length, mm

215/215

Magazine capacity

30/30

Packing

40x46 mm Rounds RLV-S&F with Sound and Flash Grenade

RLV-S&F

NSN: 1310-50-000-5266

The Rounds 40x46 mm RLV-S&F are used to incapacitate criminals, handle hostage situations, as well as, assist counter terrorist operations.
The Grenade stuns and immobilizes the people in the near vicinity by means of loud, temporarily paralyzing noise and blinding flash.

Overview

The rounds are designed to be fired from:

- Underbarrel Grenade Launchers: ARSENAL UBGL-M6, UBGL-M7,UBGL-M8,UBGL-M16; M203; FN GL1; HK269; AG36, etc.;

- Stand-alone Grenade Launchers: ARSENAL SAGL, HK169; HK269; FN GL-S; M320, etc.;

- Multi-shot Grenade Launchers: Milkor MGL; M32 MGL; ARSENAL MSGL, etc.

Packing 3 pcs. metal airtight boxes (40 pcs. in each box), arranged in a wooden case (120 pcs. in total)	RLV-S&F
Case dimensions, mm	875x398x206
Case weight, kg	36
Case volume, m³	0.072

Specifications	RLV-S&F
Type	Low Velocity, Sound & Flash
Caliber, mm	40x46
Overall length, mm	102 max
Weight of the round, kg	0.163 max
Payload	Pyrotechnical composition creating sound and flash effect
Primer type	Percussion, Boxer
Propellant type	Double base powder
Cartridge case material	Aluminum alloy
Fuze, type	Pyrotechnical, delay time
Time of delay, s	from 1.3 to 2.7
Effective radius of shock effect, m	10
Sound pressure level, dB	165
Muzzle velocity, m/s	80
Maximal firing range, m	100
Operation temperature range, °C	from minus 43 to 52
CLASS OF EXPLOSION HAZARD :	1.4E; UN 0412
Shelf life	10 years, if stored in storeroom conditions, in the original non-opened packing of the Manufacturer, strictly observing all handling and storage instructions of the Manufacturer
